Filter for Irrigation

Short Description:

Anyou Industry provide 3/4” - 4” screen and disc filter for irrigation. The high quality filters combine large filtering area with low head loss making them ideal for high flows and large quantities of dirt. Filter body and cap connected by threaded connection to sustain high pressure & easy opening and closing. Filter the dirt in the walter, prevent clogging. Main part of head assembly.


Product Detail

Product Tags

1. Product Specification and package of the filter

Y type filter 3/4” 1” 1.2” 1.5” 2”-small 2” 2.5”
Max. pressure 8bar 8bar 8bar 8bar 8bar 8bar 8bar
Mesh 120 120 120 120 120 120 120
Max. flow 5m³/h 6m³/h 15m³/h 15m³/h 10m³/h 15m³/h 35m³/h
QTY/CTN (PC) 40 40 16 16 16 12 8
G.W/CTN-Screen filter (KG) 13 13 12 12 13 13 13
G.W/CTN-Disc filter (KG) 17 17 16.5 16.5 17 17 17
Vol./CTN (M³) 0.09 0.09 0.09 0.09 0.09 0.1 0.1



T type filter 1.2” 1.5” 2”-small 2” 2.5” 3”
Max. pressure 8bar 8bar 8bar 10bar 10bar 10bar
Mesh 120 120 120 120 120 120
Max. flow 15m³/h 20m³/h 20m³/h 30m³/h 40m³/h 50m³/h
QTY/CTN (PC) 10 10 10 1 1 1
G.W/CTN-Screen filter (KG) 12.5 12.5 12.5 5.8 5.8 7.3
G.W/CTN-Disc filter (KG) 15.5 17.5 17.5 7.3 7.5 9.3
Vol./CTN (M³) 0.1 0.1 0.1 0.06 0.06 0.07



H type filter 3” 4” 4”-long
Max. pressure 10bar 10bar 10bar
Mesh 120 120 120
Max. flow 50m³/h 70m³/h 100m³/h
QTY/CTN (PC) 1 1 1
G.W/CTN-Screen filter (KG) 7.5 7.5 9.5
G.W/CTN-Disc filter (KG) 11 11 13.5
Vol./CTN (M³) 0.08 0.08 0.11

2. Product Feature of the filter

(1) Maximum quality and safety in filtration in a wide range of filtration grades in discs and screens.

(2) Dismantable, removable cap, filter elements can be taken out for easy cleaning.

(3) High quality plastic body withstands UV radiation, chemicals

(4) Long-lasting performance and labor-saving maintenance.
