Plastic Impact Sprinkler AY-5104A

Short Description:

Four nozzles plastic impact sprinkler with 1″ female thread connection and diffuser pin. POM plastic body and stainless steel spring withstands chemicals, UV radiation, and accidental impact. For field crops, vegetable and lawn by over head irrigation.


Product Detail

Application & Package

FAQ

Product Tags

1. Product Parameter(Specification)of the plastic impact sprinkler AY-5104A

Size 1″ female thread
Material POM+stainless steel
Nozzle quantity 4 nozzles
Pressure 2-5 bar
Radius 18-26 m
Flow rate 4-6 m³/h

2. Product Feature of the plastic impact sprinkler AY-5104A

(1) Well balanced for water distribution with maximum water-use efficiency

(2) Diffuser pin and diffuser arm improves water distribution pattern and uniformity

(3) Nozzles with integrated stream straightening vane for long distance

(4) POM plastic body withstands UV radiation, chemicals and accidental impact

(5) Spring is made of stainless steel

(6) Rotation speed adjustable with the spring part on the top

(7) More stable movement with metal weight hammer on the arm

(8) Two removable end cap inside of two thread connection nozzles, so four nozzles sprinkler can be three nozzles sprinkler or two nozzles sprinkler

(9) Long-lasting performance and labor-saving maintenance

(10) Reduced sensitivity to clogging and higher resistance to wind

1-inch-sprinkler-with-4-nozzles


  • Previous:
  • Next:

  • 1.Application of the plastic impact sprinkler AY-5104A

    Over head sprinkler irrigation for field crops, vegetable and lawn.

     2.Package

    Photo Description Size QTY/CTN Vol./CTN G.W/CTN
    PC KG
     5105 Plastic impact sprinkler
    AY-5105
    1” female thread 50 0.08 16
     5104 Plastic impact sprinkler
    AY-5104
    1” female thread 50 0.08 15
     5104 2 Plastic impact sprinkler
    AY-5104A
    1” female thread 50 0.08 15.5
     AY-5103 Plastic impact sprinkler
    AY-5103
    1” female thread 50 0.08 14.5
     5101 Plastic impact sprinkler
    AY-5101A
    1” female thread 50 0.08 18.5
     AY-5300 Metal impact sprinkler
    AY-5300
    1” female thread 35  0.037 17
     AY-9590 Rapid water valve
    AY-9590
    1” male thread 34 0.053 7.5
     RAIN GUN Rain gun PY40
    AY-1040
    2″ 10 0.076 21

    (1) What’s the main material of plastic impact sprinkler AY-5104A?

    A: POM

    (2) What’s the spring material of plastic impact sprinkler AY-5104A?

    A: Stainless steel ( SS )

    (3) Plastic impact sprinkler AY-5104A, part circle ( angle adjustable) or full circle?

    A: 360 degree full circle

    (4) Is the plastic impact sprinkler AY-5104A resistant to UV radiation?

    A: Yes. High quality plastic body withstands UV radiation, chemicals and accidental impact

    (5) Why two nozzles do not spray water?

    A: Because two removable end cap inside of the nozzles. End cap is useful, four nozzles sprinkler can be three nozzles sprinkler or two nozzles sprinkler

    (6) Can you provide C/O certificate of origin?

    A: Yes. C/O, Invoice, Packing list, Original B/L

    (7) Are you sprinkler factory or trading?

    A: We are factory. Welcome to our company Baoding Anyou Industry Co.,Ltd in Baoding China.
